Will it fit your vehicle?
Confirm before you buy. Free return shipping if it doesn't fit.
BBB Industries 213-0122 Rack and Pinion Assembly
| Brand | BBB Industries 213-0122 |
|---|---|
| Bushings Included | Yes |
| Distance Between Mounting Holes (In) | 14.125 |
| Distance Between Mounting Holes (mm) | 358.775 |
| Hydraulic or Electric | Manual |
| Inner Tie Rods Included | Yes |
| Input Shaft Diameter (In) | 0.654 |
| Input Shaft Diameter (mm) | 16.599 |
| Input Shaft Length (In) | 2.5 |
| Input Shaft Length (mm) | 63.5 |
| New or Remanufactured | Remanufactured |
| Number of Mounting Holes | 4 |
| Outer Tie Rods Included | No |
| Pressure Port Thread Size | Not applicable |
| Rack Length (In) | 41.438 |
| Rack Length (mm) | 1052.525 |
| Return Port Thread Size | Not applicable |
| Turns Lock To Lock | 2.06 |
| Product line | Reman Rack and Pinion |
| Fits | Hyundai · 4 vehicles |
Remanufactured unit. Rebuilt steering rack and pinion assembly for replacement use.
Inner tie rods included. Simplifies sourcing for a complete steering gear service.
Manual steering design. Uses a non-hydraulic configuration with no pressure or return ports.
Cross-references 56500-1M100, 56500-2L301 and 19382826 for the same application. See all 3.
Will it fit your vehicle?
Free return shipping if it doesn't fit.
Remanufactured steering rack
This BBB Industries reman rack and pinion assembly, part number 213-0122, is built for Hyundai Elantra applications with power steering and 17-inch wheels. It is a manual steering gear assembly with included inner tie rods and bushings for a direct replacement approach.
Key features
- Remanufactured steering rack and pinion assembly
- Manual hydraulic or electric configuration: manual
- Inner tie rods included; outer tie rods not included
- Four mounting holes with a 14.125-inch mounting-hole spacing
- 2.06 turns lock to lock for responsive steering feel
- Part number 213-0122 for fitment lookup and ordering
Detailed fitment and design
Fits 2011-2012 Hyundai Elantra, N/A, and Fits 2009-2010 Hyundai Elantra, N/A. The 213-0122 rack and pinion assembly measures 41.438 inches in rack length and uses a 0.654-inch input shaft diameter with a 2.5-inch input shaft length. Pressure and return ports are not applicable, which matches the manual steering configuration. This part cross-references Hyundai OE numbers 56500-1M100 and 56500-2L301, as well as 19382826, for the same application.
Common replacement needs
- Excessive steering play or looseness
- Uneven steering response during turning
- Worn internal rack components
- Leaking or damaged steering gear assembly
Installation notes and quality assurance
Verify wheel size, steering configuration, and mounting dimensions before installation. Confirm the input shaft dimensions and mounting-hole spacing against the original steering gear to ensure proper alignment. BBB Industries remanufactured steering components are rebuilt for replacement use, and part number 213-0122 is identified for the listed Hyundai Elantra applications.
| Year | Make | Model | Liters | Cylinders | Notes |
|---|---|---|---|---|---|
| 2012 | Hyundai | Elantra | 2.0L | L4 | Power Steering; w/ 17" Wheels; Reman Rack and Pinion |
| 2011 | Hyundai | Elantra | 2.0L | L4 | Power Steering; w/ 17" Wheels; Reman Rack and Pinion |
| 2010 | Hyundai | Elantra | — | — | Power Steering; w/ 17" Wheels (Electronic Steering); Reman Rack and Pinion |
| 2009 | Hyundai | Elantra | — | — | Power Steering; w/ 17" Wheels (Electronic Steering); Reman Rack and Pinion |
